Diaphragmatic hernia with isolated shoulder pain evoked by surfeit

Case presentation

Congenital diaphragmatic hernia (CDH) in newborns and infants requires urgent operation due to instability of vital signs (1). However, adult diaphragmatic hernia is extremely rare and symptoms are sometimes vague or absent (2,3). Moreover, it is sometimes hard to diagnose only by chest computed tomography (CT), so inevitable surgical exploration, whether it was a thoracic or abdominal approach, is required (4,5), but there are still debates about the necessity of surgery (3).

Shoulder pain can be presented in diaphragmatic hernia but it usually accompanied with dyspnea, dysphagia, or chest discomfort in massive hernia (6). Although mediastinal mass could make an isolated shoulder pain (7) but it was hard to assume that a small-sized diaphragmatic hernia was the only cause of isolated shoulder pain and whether it would disappear by surgical reduction. Here we present the rare case of small-sized diaphragmatic hernia accompanying isolated shoulder pain resolved clearly after surgical reduction. Written informed consent was obtained from the patient for publication of this case report and any accompanying images.

A 25-year-old male was referred to the hospital because of a mass on left diaphragm. The chief complaint was an isolated left shoulder pain that was evoked by surfeit. It developed every time he was overeating and persisted 60 to 90 minutes with 3 to 5 scores of numeric rating scales. There was no past medical history including trauma and orthopedics could not find any problems in the shoulder. Chest CT showed a homogeneous fatty mass on the left diaphragm. Since there was a continuity between the abdominal mesentery and the mass, it was assumed that diaphragmatic hernia, but it was uncertain radiologically (Figure 1). Further gastrointestinal work-ups did not performed because it seemed hard to offer additional information. Although there were neither pains nor signs of strangulation or infection, exploratory video-assisted thoracic surgery (VATS) was decided to confirm the characteristics of the mass.

Figure 1 The CT image showing a diaphragmatic mass (wide arrow) of homogeneous fat tissues. It seemed to connect with mesentery via diaphragmatic hole (narrow arrow). CT, computed tomography.

Surgical exploration is performed under general anesthesia via double lumen endotracheal intubation. Left pleural space was explored though the 7^th intercostal space with 10 mm thoracoscopy and then additional 5 mm port was created on the 5^th intercostal space crossing anterior axillary line. The fatty mass was noted on the posterolateral side of left diaphragm and partly adhered to it (Figure 2A). The mass has stalk and surrounding diaphragmatic defect were found. The mass seemed to have escaped through the defect. Mini-thoracotomy was performed via 7^th intercostal space because it could not have restored into abdominal cavity by VATS. Diaphragm adjacent to the stalk was incised, and it was found that the hole and stalk was firmly adhered together (Figure 2B). With careful dissection, the stalk was mobilized from the hole and the mass was restored into the abdominal cavity through the hole. The diaphragm was repaired with interrupted monofilament suture (PROLENE^® 1-0 by Ethicon Inc., Somerville, USA). He was discharged on the 5^th postoperative day without complications. Shoulder pain disappeared after operation and did not develop until the recent follow-up at outpatient clinic (99^th postoperative day).

Figure 2 Surgical views of the diaphragmatic mass. (A) Fat mass without signs of strangulation or infection was found; (B) there is a stalk and it was tightly adhered around the hole.

Discussion

Diaphragmatic hernia with isolated shoulder pain was treated successfully after surgical reduction. It was thought to be the Bochdalek hernia because abdominal contents were on posterolateral portion of left diaphragm and the patient had no trauma history. This is the first case of isolated shoulder pain evoked by small-sized CDH within the scope of our knowledge.

Shoulder pain without regional problem is recognized as a kind of referred pain from phrenic nerve or diaphragm irritation. For example, irradiation to phrenic nerve has shown to be effective for shoulder pain in the case of thymic carcinoma (7). With our report, it was known that isolated shoulder pain without local cause could be developed by diaphragmatic hernia and it can be treated with surgical reduction. Therefore, surgical exploration would be inevitable in symptomatic CDH patients in spite of the size of defect.

However, imaging follow-ups rather than exploration would be another option for asymptomatic patients. As in our case, there was no evidence of incarceration or strangulation preoperatively. It may be because the stalk of the mass was firmly adhered in the hole of diaphragm, so it seemed that additional abdominal contents were hard to move into thoracic cavity. So, follow-ups without exploration can be recommended in incidentally founded, asymptomatic small-sized CDH patients.

In summary, isolated shoulder pain could be a manifesting symptom in adult CDH and it can be treated with surgical reduction. However urgent surgery may be unnecessary in asymptomatic, small-sized CDH patients, because of tight adhesion around the hernia.

Acknowledgements

None.

Footnote

Conflicts of Interest: The authors have no conflicts of interest to declare.

Informed Consent: Written informed consent was obtained from the patient for publication of this case report and any accompanying images.

References

1. Schneider A, Becmeur F. Pediatric thoracoscopic repair of congenital diaphragmatic hernias. J Vis Surg 2018;4:43. [Crossref] [PubMed]
2. Bianchi E, Mancini P, De Vito S, et al. Congenital asymptomatic diaphragmatic hernias in adults: a case series. J Med Case Rep 2013;7:125. [Crossref] [PubMed]
3. Takahashi R, Akamoto S, Nagao M, et al. Follow-up of asymptomatic adult diaphragmatic hernia: should patients with this condition undergo immediate operation? A report of two cases. Surg Case Rep 2016;2:95. [Crossref] [PubMed]
4. Shen YG, Jiao NN, Xiong W, et al. Video-assisted thoracoscopic surgery for adult Bochdalek hernia: a case report. J Cardiothorac Surg 2016;11:165. [Crossref] [PubMed]
5. Tonini V, Gozzi G, Cervellera M. Acute pancreatitis due to a Bochdalek hernia in an adult patient. BMJ Case Rep 2018;2018.
6. Kohli N, Mitreski G, Yap CH, et al. Massive symptomatic right-sided Bochdalek hernia in an adult man. BMJ Case Rep 2016;2016.
7. Dee SW, Kao MJ, Hong CZ, et al. Chronic shoulder pain referred from thymic carcinoma: a case report and review of literature. Neuropsychiatr Dis Treat 2012;8:399-403. [PubMed]
