Establishment and characterization of a novel human osteosarcoma cell line for spontaneous pulmonary metastasis research in vivo

Introduction

Osteosarcoma is the most common malignancy of bones in humans, which accounts for ~2.4% of childhood tumors (1). The incidence peaks during the second decade of life, and the tumors mainly localize in the distal femur and proximal tibia (2,3). For most local lesions, osteosarcoma can be surgically cured with a 5-year survival of ~50% to 65% (4,5). Meanwhile, approximately 80% of patients have metastatic diseases (6,7), especially pulmonary metastases, which accounts for the top cause of death (8,9).

In spite of the advances achieved in the treatment, the mechanism underlying tumor progression and metastasis remains elusive. A transplanted-tumor animal model is necessary to clarify the mechanism underlying the progression and metastasis of osteosarcoma in vivo (10). A previous study reported the establishment and characterization of a model. In this study, human osteosarcoma cells were transformed with v-Ki-ras, and were producible for pulmonary colonies by intravenous injection into nude mice (11). However, an animal model with a transplanted primary solid tumor that can develop spontaneous pulmonary metastasis has been less reported.

In this study, we developed a novel human osteosarcoma cell line that was suitable for establishing a transplanted primary solid tumor and developing a spontaneous pulmonary metastasis in animals.

Methods

Human osteosarcoma xeno-transplantation

Human primary osteosarcoma tissues were obtained from a 16-year-old boy with osteoblastic osteosarcoma, which was in accordance with the ethical guidelines established by Shanghai Ruijin Hospital. Fresh osteosarcoma tissues (named WJ0823, P0) were dissected into small pieces (3×3×1 mm³) at 4 °C, and implanted subcutaneously into the two flanks of 6-to-8-week-old female NOD/SCID mice (P1) through a 3-mm incision. Then, tumor tissues from the xeno-grafts were dissected into small pieces (2×2×1 mm³) and implanted into the 2flanks of another NOD/SCID mouse (P2) for further passage. All animal experiments were in accordance with the approved guidelines provided by the Laboratory Animal Resource Center of Shanghai Jiao Tong University School of Medicine.

Human osteosarcoma protein marker detected by hematoxylin and eosin (HE) staining and immunohistochemistry

This patient’s osteosarcoma tissues including P0, P1, and P2 tissues were fixed in 10% buffered formalin and decalcified. All tissues were routinely embedded in paraffin and 3 non-sequential sections/animal were obtained. The tissues were subjected to Cal-Ex solution overnight. Then, all tissues were cut into 5 µm sections and stained with hematoxylin and eosin according to the manufacturer’s instruction.

These tissues were tested for alkaline phosphatase (ALP, Abcam, UK, 1:1,000), SSEA-4 (Santa Cruz, USA, 1:1,000), and CD44 (BD, USA, 1:1,000) expression by immunohistochemistry using a StreptAvidin-Biotinylated Peroxidase complex (ABC) kit (Boster, China) according to the manufacturer’s instruction.

All the slides were examined using alight microscope (Olympus BX60).

Preparation, purification, and characterization of Well5 cell suspensions from induced subcutaneous tumors at the flank of the mice

The subcutaneous tumors (P2) at the flank of the mice were harvested 6 weeks after tumor inoculation, and a single-cell suspension was prepared by digesting tumor tissue (4 mm³) with type IV collagenase for 1 h at 37 °C. Then, cells were washed in PBS3 times, and grown in DMEM Medium (Life Technologies, USA) supplemented with 10% FBS (Life Technologies, USA) at 37 °C in a 5% CO₂ incubator. Flow cytometric analysis was used to distinguish between CD44⁺ human (BD, USA) cells and CD44⁻ mice cells. Cells were suspended in FACS buffer (PBS containing 1% FBS, with or without 0.1% Na3N) and subsequently stained with fluorochrome-conjugated antibodies. Then, data were analyzed with either FlowJo software (Tree Star, Ashland, OR, USA) or Summit software (Beckman coulter). Finally, CD44⁺Cellswere sorted by MoFlo and suspended into DMEM supplemented with 2% FBS.

Sorted CD44⁺ cells were passaged two times in vitro, and then digested and diluted into 10 divisions. Each division was digested and diluted repeatedly until the purity of the diluted osteosarcoma cells was close to 100%. Well5 cells were tested for SSEA-4 expression by immunofluorescence and SSEA-4 (Santa Cruz, CA, USA, 1:1,000), CD44 (BD, USA, 1:1,000), CD105 (BD, USA, 1:500), and CD166 (BD, USA, 1:500) expression by flow cytometry.

Induced differentiation of Well5 cells in vitro

Well5 cells were seeded at a density of 26,000 cells/cm² and cultured either in proliferation medium or inadipo-maintenance medium [α-MEM supplemented with 10% FBS, 1% PSN, and 10 µg/mL insulin (Sigma, Cat#I-6634)] for 24 h followed by cultivation in adipo-induction medium [α-MEM supplemented with 10% FBS, 1% PSN, 1 µM dexamethasone (Sigma, Cat#D-4902), 10 µg/mL insulin, 0.5 mM isobutyl-1-methylxanthine (Sigma, Cat#I-5879), and 200 µM indomethacin (Sigma, Cat#I-7378)] for 72 h.

To induce differentiation, Well5 cells were seeded at a density of 2,000 cells/cm² and cultured either in proliferation medium or in differentiation medium [α-MEM supplemented with 10% FBS, 1% PSN, 10 nM dexamethasone, 50 mM ascorbate-2-phosphate, 2 mM β-glycerophosphate (Sigma, #G-9891), and 10 nM 1,25-dihydroxyvitamin D3 (Sigma, #D-1530)]. The media were replaced every 3–4 days for up to 7 days.

In vitro cell scratch and proliferation assay

A scratch was made across the monolayer of Well5 cells seeded in 6-well plates. Well5 cells were seeded at a density of about 2.5×10⁵ cells/well in complete medium (DMEM with 10% FBS). When the well was covered with Well5 cells, scratch was performed. Images of the scratches were captured at 0 and 24 h using inverted microscope (IX73, Olympus, Tokyo, Japan). CCK-8 assay (Dojindo, Rockville, MD, USA) was used to investigate cell proliferation. Briefly, 100 µL of cell suspension (5,000 cells/well) were seeded in a 96-well plate, and incubated in a humidified incubator at 37 °C for 24 h. Then, 10 µL of CCK-8 was added in each well, and incubated at 37 °C for 2 h. Finally, OD 450 nm was measured using a microplate reader.

Orthotopic intratibial injection and monitoring tumor growth and metastasis

A total of 24 BALB/c nude mice were anesthetized with ketamine (100 mg/kg). Well5 cells (1×10⁶ cells in 200 µL PBS) were injected into the proximal tibia of the mice. The tumor size was measured every 3 days, and the primary tumors and pulmonary metastatic lesions were harvested at 4, 6, and 8 weeks after injection. The metastatic lesions were fixed in 10% formalin, and embedded in paraffin. Then, 3 non-sequential serial sections/animal were stained with HE staining form icroscopic metastasis analysis.

In vivo imaging system (IVIS)

Luciferin was injected into the intraperitoneal cavity ~5 minutes before imaging at a dose of 150 mg/kg. Mice were then placed on the imaging stage to collect ventral and dorsal images using the IVIS (Xenogen Corp., Alameda, CA, USA). Photons emitted from the primary tumors and pulmonary metastatic lesions were quantified using Living Image software (Xenogen Corp., Alameda, CA, USA).

Statistical analysis

SPSS19.0 software package was used for data analysis. Measurement data are presented as mean ± SD of 3independent experiments. Student’s t-test for unpaired variables was used to determine statistical significance of differences between the groups, and a P<0.05 was considered statistically significant.

Results

Characterization of human osteosarcoma tissues and tissue transplantation

Firstly, we identified the WJ0823 human osteosarcoma tissues by immunohistochemistry staining, human osteosarcoma cells were pleomorphic and positive with alkaline phosphatase reaction, SSEA-4, and CD44 (Figure 1A). The genetic background of human osteosarcoma detected by fluorescence in situ hybridization (FISH) showed that retinoblastoma (Rb) gene was deficient (data not shown). To identify the tumorigenicity of parent osteosarcoma tissue, we subcutaneously inoculated minced human osteosarcoma tissue into NOD/SCID mice; the primary specimens generated passage 1 (P1) (Figure 1B; b1,b3) and passage 2 (P2) xenografts (Figure 1B; b2,b4). In addition, in animals injected with human osteosarcoma tissues, the tumors caused a destruction of tibia by X-ray images, including bone destruction of the right tibia and parenchyma mass accompanied by osteogenesis (Figure 1B; b5). Meanwhile, the different quantitative and morphologic neoplastic osteoids were observed by HE staining. The neoplastic osteoid existed in all the tissues with the background of malignant sarcomatoid cells. The typical neoplastic osteoids were irregular in a lace-like, network, or filigree osteoid pattern, and atypical neoplastic osteoblast was observed in normal remnant bone (Figure 2A).

Figure 1 Establishment of an orthotopic model of osteosarcoma and tissue profiling. (A) Immunohistochemistry staining of the WJ0823 human osteosarcoma tissues; human osteosarcoma cells were pleomorphic and positive with SSEA-4 (a2), ALP (a3), and CD44 (a4). (B) NOD/SCID mice were inoculated minced human osteosarcoma tissue; the primary specimens generated P1 (b1,b3) and P2 (b2,b4) xenografts; X-ray demonstrated the destruction of the tibia (b5).

Figure 2 HE staining of parent human osteosarcoma tissues and purification and characterization of Well5 cells from induced tibial tumors. (A) Parent (WJ0823-P0) (a2 is amplification of a1), passage 1 (WJ0823-P1) (a3) and passage 2 (WJ0823-P2). (a4) HE staining showed the formation of osteosarcoma. (B) The purity of osteosarcoma cells was close to 100% (b1,b2). Immunofluorescence showed the purification of osteosarcoma cells with SSEA-4 (b3,b4).

Characterization of Well5 cells from induced tibial tumors

The P2 orthotopic tumors were harvested and digested into single-cell suspension and plated in the dishes. After 10 generations of dilution, the purity of osteosarcoma cells was close to 100% (Figure 2B; b1,b2). We identified the purified osteosarcoma cells with SSEA-4 by immunofluorescence (Figure 2B; b3,b4) and named the purified osteosarcoma cells “Well5 cells”.

Adipogenesis, osteogenesis, migration, and proliferation of the Well5 cell line

We further successfully induced Well5 cells to differentiate into adipogenic and osteogenic cells with conditions (Figure 3A) in vitro which indicated that Well5 cells had the ability of adipogenesis and osteogenesis. Cell scratch assay and C.CK8 assay indicated that Well5 cells obtained better capacity of migration (Figure 3B) and proliferation (Figure 3C) than the MG63 cell line.

Figure 3 Adipogenic and osteogenic differentiation, migration, and proliferation of Well5 cells. In contrast to MG63 cells, we identified the adipogenesis, osteogenesis, migration, and proliferation ability of Well5 cells. (A) Well5 cells showed better abilities of adipogenesis (a2, a4) and osteogenesis (a6, a8) than MG63 (a1, a3 & a5, a7); cell scratch assay indicated Well5 cells possessed stronger migration ability than MG63 (B); (C) we used the CCK8 to detect the proliferation of Well5 and MG63 cells. N=3/group, *, P﹤0.05. (A) DAB staining.

The orthotopic model of osteosarcoma and tumor growth at the primary site and spontaneous pulmonary metastases

Next, the NOD/SCID mice were injected with Well5 cells to examine the ability of orthotopic tumor formation and spontaneous pulmonary metastasis development. As shown in Figure 4A and B, tumors were observed in all the mice, being firmly involved into the tibia, and extended into the soft tissues around the bone. Moreover, pulmonary metastases were observed in all the mice. As shown in Figure 4C and D, the pulmonary metastatic lesions extracted from Well5-cell-injected animals exhibited numerous surface metastases at as early as 6 weeks, which became more prominent by 8 weeks.

Figure 4 The destruction of the tibia and spontaneous pulmonary metastases. The destruction of the proximal tibia (A); the pulmonary metastasis image (B); histologic evaluation of the pulmonary metastases tissue (C); pulmonary metastasis histology at lower magnification (D). (D) HE staining.

Discussion

By estimate, ~10% to 20% of patients with osteosarcoma suffer from lung or bone metastasis at the time of diagnosis, and, in spite of progress achieved in recent clinical research, a large proportion of patients eventually die of pulmonary metastatic disease (12,13). There is an urgent need to develop in vivo experimental systems, which will examine tumor growth and metastasis and the development of potential therapeutic agents.

Metastatic models in experimental animals are important to clarify the mechanism underlying tumor growth and metastasis. Tumor transplantation to rodents is the conventional way to establish metastasis models (14,15). While many of these models require administration of tumor cells intravenously or subcutaneously. The establishment of human osteosarcoma animal models in nude mice has been reported in previous studies (16,17). Also, osteosarcoma was developed by injecting human tumor cells either intravenously or subcutaneously in some of these cases (18,19). These animal models might not be clinically relevant because osteosarcoma cells are not spontaneously developed. Moreover, in these cases, tumor progression and metastases do not mimic the human clinical course.

In Jia et al.’s study, it was reported that a novel cell line named Saos-LM6 was isolated after 6 repeated cycles of tumor cells in xenograft mice (16), which was featured by pulmonary metastases. Su et al. established another new highly metastatic osteosarcoma cell line named MG63.2 from the parental MG63 cells (20). In the present study, we established a novel human osteosarcoma cell line, which was characterized by the development of spontaneous pulmonary metastasis after orthotopic implant of tumor cells. In the study, we found that Well5 cells could be orthotopically transplanted into NOD/SCID mice and that this resulted in local tumor invasion surrounding tissues and numerous spontaneous pulmonary metastases in a reproducible and quantifiable manner. Furthermore, Well5 cells presented a stronger ability for adipogenesis, osteogenesis, migration, and proliferation than MG63 cells. In this model, tumor progression and metastasis followed a human clinical scenario, which makes it a promising and reliable system for the evaluation strategy against osteosarcoma, especially against post-surgical micrometastatic disease.

In conclusion, our study established a novel osteosarcoma cell line namedWell5, which possessed osteoblast-like characteristics and might be a useful model for biological studies of osteosarcoma, and the development of novel strategies against osteosarcoma.

Acknowledgments

Funding: This research was supported by the Chinese National Natural Science Foundation (No. 81172550).

Footnote

Conflicts of Interest: The authors have no conflicts of interest to declare.

Ethical Statement: All animal experiments were in accordance with the approved guidelines provided by the Laboratory Animal Resource Center of Shanghai Jiao Tong University School of Medicine. All the authors are accountable for all aspects of the work, and the questions related to the accuracy or integrity of any part of the work are appropriately investigated and resolved.
