Continuous endobronchial suctioning for refractory post lobectomy lung atelectasis: a case report

Introduction

Pulmonary infectious complications are common after lung resections mainly with the form of atelectatic lung collapse and pneumonia (1). Development of such complications may lead to increased length of stay, length of stay in intensive care unit as well as increased 30-day and 90-day mortality (2). The severity of these complications is influenced by many factors i.e., their extent and mechanism of development, patient vulnerability, the compensatory reserves and others (3).

Conservative treatment of these complications usually includes antibiotics, use of mycolytics for reduced secretion volume, aggressive physiotherapy etc. (1,3). In some cases, more aggressive interventions may be needed i.e., non-invasive ventilation and direct airway suctioning (with bronchoscopy or a tracheostomy) (1,3). There are, however, rare cases in which the collapse persists, despite all the aforementioned measures, leading to the need for improvisation in an effort to avoid further surgery, which in borderline patients can be detrimental (4,5).

We herein present the technique of continuous endobronchial suctioning in a patient who after a complicated redo thoracotomy for lung cancer developed refractory collapse of the remaining upper lobe. This technique may be proven invaluable in the treatment of such demanding cases wherever the usual conservative measures fail. This article is presented in accordance with the CARE reporting checklist (available at http://dx.doi.org/10.21037/atm-20-3839).

Case presentation

Patient information

A 70-year-old male was referred electively to our department for curative treatment of lung cancer with enlarging right lower lobe lesions.

Nine months before this referral the patient had undergone a right middle lobectomy for a similar cancer. This was performed via a double thoracotomy (entrance in chest via 2 thoracotomies but with one skin incision) which left a fluid-filled space between the upper and lower lobe (Figure 1).

Figure 1 Preoperative CT chest scan of the patient showing the lesions in the right lower lobe. It also shows the space in between the upper and lower lobe from where the middle lobe was previously resected. The anterior hilum is shown to be severely fibrosed and calcified.

The lesions were positron emission tomography (PET) avid (i.e., positive) and were proven on computed tomography (CT) guided biopsy to represent lung cancer (Figure 1).

His past medical history was significant mainly for ankylosing spondylitis with “bamboo spine” for which he was on methotrexate and steroids (20 mg/day). He also reported hypertension, history of bronchiectasis and previous pulmonary embolism (PE) for which he was on long-term anticoagulation. He was an ex-smoker with 40 pack years of smoking history.

His performance status was 0 but his lung function tests were borderline: Forced expiratory capacity in 1 sec (FEV₁) =54% (1.2 liters) and Diffusional Capacity for Carbon Monoxide (DLCO) =65%. His cardiopulmonary exercise test showed an MVO₂=20.1 (70.6%) and VE/VCO₂ =29.

Apart from the lung multidisciplinary team (MDT) meeting, his case was discussed at the department’s high-risk MDT and the decision was to proceed to a resection.

After a copious mediastinoscopy which was negative, he went on to have a redo right thoracotomy. Entrance in the chest was copious and demanding as the space was totally obliterated. Similarly, the hilum was fibrosed and access to the major vessels was eventually achieved intrapericardially. Based on the patient’s co-morbidities, lung function and his long treatment with steroids, a pneumonectomy was decided to be avoided and therefore an intrapericardial lower lobectomy was performed. The remaining upper lobe re-expanded but its inferior surface was importantly lacerated (Figure 2).

Figure 2 Chest X-ray obtained immediately postoperatively. The remaining right upper lobe is expanded but severely lacerated at its inferior aspect. There is also substantial pleural space.

Clinical findings

On postoperative day (POD) 1 the patient was well and received vigorous physiotherapy with mobilization and treatment with nebulizers (salbutamol 2.5 mgs four times/day, normal saline 0.9% 5 mLs four times/day).

On POD 2 unfortunately he developed type 1 respiratory failure with increased oxygen requirements (from nasal cannula 3 litres to face mask 40%). On examination, respiratory rate was elevated (30 breaths/min) and accessory breathing muscles were used. There were no breathing sounds heard on the operated side.

Timeline

The postoperative events are outlined in Table 1.

Table 1 Timeline of events after redo-surgery (time point 0)
Full table

Diagnostic assessment

On POD2 a totally occluded RUL i.e., a “white out” (Figure 3) was found on his chest X-ray. Under the fear of lung torsion/infarction or a new massive PE, an urgent CT Chest was conducted on the same day, which showed patent vessels to the lobe and a totally atelectatic lung with mucous plugging of the main airways (Figure 4). His inflammatory markers got worse on that day: white blood cell count (WBC) =23,100×10⁹/L and C-reactive protein (CRP) =138 mg/L.

Figure 3 Chest X-ray obtained on postoperative day 1. A total atelectasis i.e., “white out” of the lung is noted.

Figure 4 A CT chest of the patient was obtained on postoperative day 3 as the “white out” was refractory to any treatment up to that day. The scan showed totally atelectatic lung with some areas of aeration and patent main vessels.

The working diagnosis at this point therefore was respiratory failure/respiratory infection because of total atelectasis/pneumonia of the remaining RUL.

Failure to treat this sequeala would necessitate return to theatre for a high-risk pneumonectomy in terms of morbidity/mortality (i.e., bronchopleural fistula, empyema, urgent pneumonectomy in an infected space, longstanding lung infection/collapse, respiratory failure, intensive care unit stay).

Therapeutic intervention

Upon diagnosis, the patient was started on antibiotics (Piperacillin/Tazobactam 4.5 grs every 8 hours) and mucolytics (Carbocisteine 325 mg every 8 hours) on top of his nebulizers.

On POD 3, the patient returned to theatre for bronchoscopy. A tracheostomy (Size Fr 8.0) was additionally inserted.

Despite regular suctioning and vigorous physiotherapy for 2 days (POD 4 and 5) his “white out” did not improve. Additionally, the patient needed sedation for every bronchoscopy (as he could not tolerate it), his airways filled up with pus and creamy secretions almost immediately after every bronchoscopy (Figure 5) and blind suctioning through the tracheostomy was risky because of the bilobectomy bronchial stump.

Figure 5 Repeated bronchoscopies showed thick and creamy secretions originating from the right main bronchus.

On POD 6 and after all treatment measures have failed, returning to theatre for a high-risk pneumonectomy was the only choice left at this point.

As a last resort to avoid this high-risk reoperation/completion pneumonectomy, a decision was made to sedate the patient and leave a suction catheter through his tracheostomy inside the RUL bronchus.

A suction catheter (16 Fr) was placed inside the RUL bronchus under bronchoscopic guidance (Figure 6) applying continuous endobronchial suction.

Figure 6 A suction catheter was left inside the right upper lobe bronchus orifice under bronchoscopic guidance. On this image, the bronchial intermedius stump and the carina are noted for reference.

The rationale was to continuously provide suction to the infected lung, keeping airways clear in order to allow time for his lung to heal with antibiotics and steroids.

Follow-up and outcomes

The bronchoscopic picture (Figure 7), the “white out” on chest X-ray (Figure 8) and his inflammatory markers improved within the next 2 days (from POD 7) after which his sedation was discontinued.

Figure 7 Clear orifice of the right upper lobe bronchus after removal of the catheter.

Figure 8 Chest X-ray obtained on the day the catheter was removed which shows aerated lung without a noticeable pleural space.

He was discharged from ICU on POD 13 but he needed a long recovery (patient followed physiotherapy sessions), insertion of a long term drain for infected pleural effusion and was eventually discharged home a month later in good condition appreciating the outcome.

The patient unfortunately passed away a couple of months later because of type 2 respiratory failure.

Helsinki declaration

All procedures performed in studies involving human participants were in accordance with the ethical standards of the institutional and/or national research committee(s) and with the Helsinki Declaration (as revised in 2013). Informed consent was obtained from the patient.

Discussion

We present the technique of continuous endobronchial suctioning with a suction catheter left directly inside the RUL bronchus in a patient who developed a refractory atelectasis after complicated redo lung resection. This is the first time, to our knowledge, that such a technique is reported, and it may help physicians treating similar complicated situations in the future.

Lobar atelectasis postoperatively is a usual complication which can vary in severity (3). It could represent a simple atelectasis seen on a chest X-ray requiring simple conservative treatment measures and physiotherapy or a severe pneumonia requiring, apart from antibiotic therapy, admission to a high dependency/intensive care unit. Bronchoscopy, preferably with a rigid bronchoscope +/− tracheostomy are frequently required especially in cases with relapse (6,7). In our case, the patient developed a total “white out” postoperatively not been able to be treated with usual conservative measures. Moreover, it was a complicated case as even back to back bronchoscopies were unsuccessful leading to quick re-accumulation of creamy secretions originating from the periphery of the remaining lung.

In this “uncharted” postoperative recovery situation we improvised by leaving the catheter inside the source of secretions i.e., the RUL bronchus (the remaining after the lower bilobectomy) leaving time for the infection to subside, keeping the airways and the bilobectomy bronchial stump clear and at the same time avoiding trauma to it from blind suctioning through the tracheostomy. Other authors have published such endeavors for example using DNase instillation in the airways or using double lumen endotracheal intubation for left lung atelectasis (4,5). To our knowledge this practice of leaving a catheter inside the airways for continuous suctioning is reported for the first time.

Unfortunately, the patient passed away 4 months later from a non-cancer-related issue following the projection of lung resections in which when cardiopulmonary complications develop, patients accrue higher mortality (8).

Similarly, bilobectomies, against common belief, develop more cardiopulmonary complications rather than pleural space issues and this was verified with our case (9). Kinking of the airway of the remaining lobe because of his important collapse from his atelectasis/pneumonia could have been one of the factors that led to this ongoing lobe infection/collapse. Continuous suctioning of the lobe possibly led to subsidence of the lobe inflammation and better expansion which consequently led to less airway kinking and better secretion clearance.

Ankylosis spondylitis is a disease which can surcharge negatively to the perioperative and postoperative period after surgery (10). In our case, the patient underwent an initial double thoracotomy (no reason recorded) and lymphadenectomy which, with this underlying disease, possibly induced a profound healing process ending up in extensive fibrosis inside the chest making the redo-procedure extremely copious.

One of the limitations of this technique was the inability to manage ventilation and achieve the desired airway pressures because of leakage around the catheter inside the tracheostomy, which necessitated extra maneuvers to accomplish a tight seal. Additionally, the patient had to be sedated instead of being awake and receiving physiotherapy, which however in our case, did not yield the desired results.

In summary, in cases with important refractory atelectasis with quick re-accumulation of secretions, continuous suctioning of the airways with a suction catheter inside the airway of issue, could potentially comprise another treatment modality for physicians who face this challenging complication/pathology.
