Medial pivot knee in primary total knee arthroplasty

Total knee arthroplasty (TKA) shows generally excellent clinical results, but knee kinematics after TKA is different from physiological kinematics. Classic model of knee joint motion is the so called “four-bar link model”, in which knee kinematics is described as uniform rollback of the femur on the tibia during flexion; the anterior cruciate ligament (ACL) and posterior cruciate ligament (PCL) represent the gear enabling the femur rolling and gliding on the tibia. Normal knee kinematics has shown that knee doesn’t work following this concept. The four-bar link model applied to total knee implant design involves antero-posterior motion of the femur on the tibia (paradoxical anterior sliding of the femur) to avoid “kinematic conflict” (1): J-curve femoral components are characterized by decreasing radii from full extension to flexion exactly to allow this kinematic concept. Paradoxical anterior slide of the femur on the tibia moves anteriorly the knee axis of flexion and lessens maximum knee flexion; the quadriceps efficiency is decreased, because the quadriceps moment arm is reduced (2). Unfortunately, it seems that paradoxical anterior sliding of the femur on tibia can sometimes occur in both posterior cruciate-retaining (CR) and posterior stabilized (PS) prosthesis (3).

The physiological knee kinematics reveals that the knee moves with the medial compartment staying very nearly stable like a ball and socket joint, while the external femoral condyle moves front to back rotating around the centre of the medial side during knee flexion (4). In vivo fluoroscopic analyses of the normal human knee have however proved the medial compartment is more stable and congruent to translation than the lateral, producing a “medial pivot” motion (2). So, probably, reproducing not only posterior femoral rollback but also medial pivot motion becomes important in modern TKA (5), because a paradoxical sliding forward or paradoxical rolling forward are not physiological motions.

The medial pivot philosophy pushed since late 1990s several orthopaedics companies to create an asymmetric tibial insert with a highly congruent medial compartment and a less conforming lateral compartment; in this way anterior motion and posterior motion are limited in the ultra-congruent medial compartment, which has a ball-and-socket joint and translation in the lateral compartment in unrestricted (3). The femoral component has a single radius curvature and high conformity in the medial compartment about which it rotates; in this way the femoral implant does not roll back as in PS arthroplasty with post and cam mechanism (4) and quadriceps force is improved especially in early flexion (6). In this design antero-posterior stability is achieved with a raised anterior lip of the polyethylene insert, while is minimized the potential for condylar liftoff (3). Furthermore, radiological studies in medial pivot CR implants have demonstrated a posterior femoral translation during knee flexion: this phenomenon is considered an important kinematic factor (7). Otherwise, other authors have shown no clinical different outcome of medial pivot TKA whether the PCL was retained or sacrificed (8): they suggest to sacrifice PCL in case of difficult soft tissue balancing procedure and to increase femoral component external rotation to compensate possible medial tightening due to thickness of medial portion of the polyethylene insert. The philosophy to copy normal knee kinematics should increase stability and reduce polyethylene wear. Finally, Barnes and Blaha showed in a cadaveric knee model that kinematic performance of medial pivot implant is similar to that in normal state knee, with no difference in quadriceps extensor forces (9).

Midterm clinical and radiographic results of the medial pivot total knee system have been reported as satisfactory or excellent (5). Schmidt and Blaha published 98% excellent or good results at 5 years, with increasing range of motion from 115° at preoperative analysis to 119° at final follow-up and 96.6% component survivorship (1); according to Youm et al., this last value increases to 98.1% at 7-year follow-up with clinical satisfactory results (10). Karachalios et al. reported satisfactory clinical results with a mean knee flexion of 117° (11). A recent systematic review and meta-analysis of 1,146 medial pivot implants performed in six countries shows survivorship and Knee Society Score (KSS) similar or better than that recorded for other TKA systems (12). Medial pivot implants demonstrate a superior prognosis compared with a PS implant (13). Patients with different bilateral TKAs feel the medial pivot implant as more stable and more normal, also for highly demanding tasks as rising from a chair without compensation from non-operated limb: they prefer the medial pivot rather than mobile-bearing, CR or posterior-stabilized prostheses (3). Similarly in case of bilateral TKAs, Pritchett stressed patient’s preference at 2-year follow-up for retention of both cruciates with use of the ACL-PCL prosthesis or substituting with a medial pivot implant (6). So it seems that medial pivot knee may have advantages in terms of contact area and kinematics but not real advantage in terms of post-operative knee flexion (14). On the other hand, in vivo image registration technique of tibiofemoral contact indicates that kneeling is safe without risk of subluxation or dislocation in medial pivot implant without cam-post or PCL (15). Fluoroscopic analyses in vivo of medial pivot implant have demonstrated similar knee kinematic to physiological motion (3), as posterior translation of the lateral femoral condyle during knee flexion, and partial restoration of normal knee kinematics after medial pivot design implant in difficult knees, as severe valgus deformity (16); particularly, kinematics are similar in pattern to normal functional knees, even if smaller in magnitude, and during normal different weight bearing activities (stepping, kneeling, pivoting and lunging) no paradoxical anterior slide of the femur was demonstrated (17). Polyethylene wear particles in synovial fluid obtained 1 year after TKA appear fewer in a medial pivot implant than in a posterior-stabilized prosthesis (6); however, other studies are necessary to reach a design of tibial insert that copy knee physiological kinematics (5). Chinzei et al. demonstrated with three-dimensional digital template software that implanting a medial pivot TKA can change patello-femoral joint kinematics compared to pre-surgery kinematics (18). For some Authors the constraining shape of the polyethylene insert of medial pivot TKA can substitute the function of the PCL, but Fang et al. showed that a CR knee solely constrained by a medial pivot is not stable enough to substitute the PCL and that for regaining a normal knee motion is necessary with medial pivot implant retention of the PCL or a post-cam mechanism (19).

The benefits of medial pivot implant are antero-posterior stability, large contact area with low contact stress and high component’s compliance. Mid-term clinical and radiological results are satisfactory with elevate survival rates and no serious implant related failure. Other studies are necessary to evaluate long-term results and indications for unusual cases, as post-traumatic arthritis or severe incorrigible valgus deviation.

Acknowledgements

None.

Footnote

Conflicts of Interest: The authors have no conflicts of interest to declare.

References

1. Schmidt R, Ogden S, Blaha JD, et al. Midterm clinical and radiographic results of the medial pivot total knee system. Int Orthop 2014;38:2495-8. [PubMed]
2. Dennis DA, Komistek RD, Colwell CE Jr, et al. In vivo anteroposterior femorotibial translation of total knee arthroplasty: a multicenter analysis. Clin Orthop Relat Res 1998.47-57. [PubMed]
3. Schmidt R, Komistek RD, Blaha JD, et al. Fluoroscopic analyses of cruciate-retaining and medial pivot knee implants. Clin Orthop Relat Res 2003.139-47. [PubMed]
4. Freeman MA, Pinskerova V. The movement of the normal tibio-femoral joint. J Biomech 2005;38:197-208. [PubMed]
5. Omori G, Onda N, Shimura M, et al. The effect of geometry of the tibial polyethylene insert on the tibiofemoral contact kinematics in Advance Medial Pivot total knee arthroplasty. J Orthop Sci 2009;14:754-60. [PubMed]
6. Pritchett JW. Patients prefer a bicruciate-retaining or the medial pivot total knee prosthesis. J Arthroplasty 2011;26:224-8. [PubMed]
7. Cho SH, Cho HL, Lee SH, et al. Posterior femoral translation in medial pivot total knee arthroplasty of posterior cruciate ligament retaining type. J Orthop 2013;10:74-8. [PubMed]
8. Bae DK, Song SJ, Cho SD. Clinical outcome of total knee arthroplasty with medial pivot prosthesis a comparative study between the cruciate retaining and sacrificing. J Arthroplasty 2011;26:693-8. [PubMed]
9. Barnes CL, Blaha JD, DeBoer D, et al. Assessment of a medial pivot total knee arthroplasty design in a cadaveric knee extension test model. J Arthroplasty 2012;27:1460-8.e1.
10. Youm YS, Cho SD, Lee SH, et al. Total knee arthroplasty using a posterior cruciate ligament sacrificing medial pivot knee: minimum 5-year follow-up results. Knee Surg Relat Res 2014;26:135-40. [PubMed]
11. Karachalios T, Roidis N, Giotikas D, et al. A mid-term clinical outcome study of the Advance Medial Pivot knee arthroplasty. Knee 2009;16:484-8. [PubMed]
12. Fitch DA, Sedacki K, Yang Y. Mid- to long-term outcomes of a medial-pivot system for primary total knee replacement: a systematic review and meta-analysis. Bone Joint Res 2014;3:297-304. [PubMed]
13. Hossain F, Patel S, Rhee SJ, et al. Knee arthroplasty with a medially conforming ball-and-socket tibiofemoral articulation provides better function. Clin Orthop Relat Res 2011;469:55-63. [PubMed]
14. Shakespeare D, Ledger M, Kinzel V. Flexion after total knee replacement. A comparison between the Medial Pivot knee and a posterior stabilised implant. Knee 2006;13:371-3. [PubMed]
15. Barnes CL, Sharma A, Blaha JD, et al. Kneeling is safe for patients implanted with medial-pivot total knee arthroplasty designs. J Arthroplasty 2011;26:549-54. [PubMed]
16. Kitagawa A, Ishida K, Chin T, et al. Partial restoration of knee kinematics in severe valgus deformity using the medial-pivot total knee arthroplasty. Knee Surg Sports Traumatol Arthrosc 2014;22:1599-606. [PubMed]
17. Shimmin A, Martinez-Martos S, Owens J, et al. Fluoroscopic motion study confirming the stability of a medial pivot design total knee arthroplasty. Knee 2015;22:522-6. [PubMed]
18. Chinzei N, Ishida K, Matsumoto T, et al. Evaluation of patellofemoral joint in ADVANCE Medial-pivot total knee arthroplasty. Int Orthop 2014;38:509-15. [PubMed]
19. Fang CH, Chang CM, Lai YS, et al. Is the posterior cruciate ligament necessary for medial pivot knee prostheses with regard to postoperative kinematics? Knee Surg Sports Traumatol Arthrosc 2015;23:3375-82. [PubMed]
